Gas analyser and opacimeter EIS-5000
The gas analyser + opacimeter EIS-5000 is adapted to current regulations for vehicles with dual exhaust systems, offering the possibility to perform both measurements. The EIS-5000 provides the inspector with a simple interface to identify the engine type and applies the appropriate emission test for each vehicle.
Unique equipment on the market:
- Integrated OBD II module: Our DAD (Data Acquisition Device) performs all the functions of OBD, providing the information necessary to obtain a complete diagnosis of vehicle problems.
- Zero air generator: We are the only manufacturer to integrate this technology into the device.
- High pressure purging: It keeps the internal components clean and allows accurate results at every point of the test.
Standard equipment
- EIS-5000 cabinet with integrated gas analyser
- Opacimeter
- Sampling probe
- Special cabinet for emissions equipment
- Electronic control and SMRW Software
- Temperature gauge
- Commissioning certificate for opacimeter module F
OBD II DAD device
Technical data
Gas analyser
- Measurable gasesHC, CO, CO₂, O₂, NOx (optional)
- Calculation of Lambda factor and corrected CO
- Storage temperature-50 to 70 ºC
- Operating temperature5 to 55ºC
- Operating pressure812-1,085 mbar
- Automatic water and particle removal
- Power supply230 V 50/60 Hz
- Oil Temperature/Resolution MeterEOBD
- RPM/resolution meter 0-9.999 rpm / 10 rpm
- Lambda meter/resolution0-9,99 / 0,001 o 0,01
- Regulations it complies withOIML R99 / ISO 3930 / BAR97
- Humidity5-95% (±3%)
- Database and scrap assessment available
Opacimeter
- Environmental working conditions: TemperatureAmb. temp. in use: -10 to 55ºC / Amb. temp. in official use: 0 to 45ºC
- Environmental working conditions: Humidity30-90%
- Environmental working conditions: Pollution<2%
- Storage temperature-32 to 55ºC
- OpticsGreen light source between 480 and 680 mm, max. 565 mm
- DetectorSilicon photodiode
- Response timeFrom 10 to 90%, <0,2 s
- Acoustic noise53 dB
- Warm-up period3-6 min, depending on outside temperature
- Standard test probe745 mm / 10 mm
- Opacity (range, resolution)N: 0-100% / 0,10% K: 0,00-9,99 m-1 / 0,01 m-1
- Power supply230 V 50 Hz
- Regulations it complies withISO 11614, EMC Standard UNE 82503, NFR 10025-2016
- Measurement of the opacity at % and the absorption coefficient "k", calculated according to Beer-Lambert's Law
Gas analyser and opacimeter software
Ryme Worldwide has SMRW (Software Maquinaria Ryme Worldwide) for its equipment, which is responsible for collecting information from our equipment and peripherals, analysing it and displaying it on the information output device. All of this is accompanied by the necessary electronics to optimise performance to the maximum.
Work in your inspection centre or workshop in the fastest and most efficient way with the operation of our Ryme Worldwide Machinery Software.
A unique way of working designed to make the inspector's job easier.
No redundancies, what you need, when you need it, how you need it. Read more
